ID # 13830473

FX-742 Rotary Cutter

  • FX 742 Rotary Cutter
  • FX 742 Rotary Cutter
  • FX 742 Rotary Cutter
  • FX 742 Rotary Cutter
  • FX 742 Rotary Cutter
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
  • 42’ (12.8m) cutting width makes long days short again. Use 1 cutter where traditionally 2 or 3 cutters were needed. Cover more ground & reduce the number of tractors and fuel costs.
  • Unique 5-plex design flexibility allows for a 118” (3m) transport width.
  • Available with stump jumpers for pasture and grass maintenance or with Schulte’s fixed knife and baffle technology for mulching crop residue such as straw, corn or cotton stalks.
  • Unmatched reliability with a premium Bondioli & Pavesi SFT drive & gearbox system.
  • Size 10 main CV with an over running clutch provides worry free shut downs.
  • Fully compatible for all row crop cutting in 30”, 32”, 38”, 40” and one metre row spacing.
  • A parallel solid tongue hitch maintains even load on the tractor draw bar.
  • Full rubber grommet suspension across the entire unit reduces shock loading and maintains even cutting, even in the roughest of conditions.
  • Unique driveline arrangement allows for independent clutch protection for each down rotor.
  • A continuously welded 10 gauge domed deck adds strength and durability.
Specifications
Model
FX-742 Rotary Cutter
Year
2014
Sale Type
New
Manufacturer
Serapid
Cutting Width
42ft (12.8m)
Overall Width
42.9ft (13.1m)
Overall Length
24.25ft (7.4m)
Cutting Height
2" - 16" (51mm - 406mm)
Transport Width
118" (3m)
Row Crop Wheel Trans Width
146” (3.7m)
Transport Height
165" (13.75 ft or 4.2 m)
Weight 18,000lbs
(8165 kg) depending upon configuration
Hitch Weight
6,500lbs (2950 kg) depending upon configuration
Cutting Capacity
2" (51mm)
Minimum Tractor Size
250 hp (186 kW) ensure drawbar can support weight
Blade Tip Speed
16,300 ft/min (4970 m/min)
Blade Overlap
6.5" (165mm)
Divider Box Rating
350 hp (261 kW)
T Box Ratings
180 hp (134 kW)
Down Box Ratings
210 hp (157 kW)
Deck Thickness
134" (10 ga) (3.4mm)
Skirt Thickness
1/4" (6.4mm)
Inside Wing Operating Range
11° down to 13° up
Outside Wing Operating Range
8° down to 10° up
