Vermeer VSR540 Single-screw Vertical Mixer

Listing image Listing image Listing image Listing image
Specifications

Model VSR540 Single-screw Vertical Mixer Category Name Agriculture Year 2025
Sale Type New Manufacturer Vermeer Odometer km
Price Contact for price CAD
Description

Built for cow-calf producers who want to maximize the value of high-roughage feed rations, the Vermeer VSR540 single-screw vertical mixer combines durability, reliability and performance for full-time or seasonal use. Equipped with essential features and designed for low-maintenance ownership, these mixers deliver ample processing power with virtually no spillage.
DIMENSIONS
Total_length
201 in (510.5 cm)
Tires_(retread)
Standard 445/50R-22.5
Maximum_net_load
11000 lbs (4989.5 kg)
Loading_height_-_standard
120 in (304.8 cm)
Machine_weight_-_standard
8920 lbs (4046 kg)
Working_width_-_50-in_folding_conveyor_extension
158 in (401.3 cm)
Transport_width_-_50-in_folding_conveyor_extension
132 in (335.3 cm)
DRIVETRAIN
Driveline
Standard: 1000 rpm, CV; Optional: 540 rpm, CV
Screw_rpm
1000-rpm configuration: 48 (1 speed) or 48/32 (2 speed); 540-rpm configuration: 40 (1 speed) or 40/27 (2 speed)
Torque_Protection
Shear bolt
OPERATIONAL
Capacity
540 cu ft (15.3 cu m)
Scale_display
Digi-Star EZ2500
Discharge_style
Side conveyor
Floor_thickness
5/8 in (15.9 mm)
Number_of_screws
1
Tub_wall_material
Regular structural steel
Tub_wall_thickness
1/4 in (6.4 mm)
Discharge_Direction
Right
Minimum_PTO_horsepower
130 hp (97 kW)
Screw_flighting_material
AR200
Screw_flighting_thickness
1/2 in (12.7 mm)
Number_of_knives_per_screw
7
Recommended_PTO_horsepower
150 hp (111.9 kw)
Folding_conveyor_extension_length
50 in (130 cm)
